What is the beam vertical plate column of the car water tank
automobile water tank beam vertical plate column refers to the support structure of the front of the automobile, mainly including the water tank beam, water tank vertical plate and water tank column and other components. Together, these components form the skeleton of the front of the car and play a role in supporting and protecting important components such as the engine and water tank.
Tank beam
The water tank beam is located in the front of the car and extends horizontally, and its main function is to support and fix the water tank, condenser and other components. It is usually bolted or spot-welded to the body stringer, ensuring the stability and safety of these components .
Tank vertical plate
The water tank vertical plate is perpendicular to the water tank beam, located on both sides of the front of the car, and its main function is to support and protect the water tank. It is usually connected with the tank beam by bolts or spot welding to form a stable frame structure .
Tank column
The tank column refers to the column structure connecting the tank beam and the vertical plate, which is usually located in the four corners of the front of the car. These columns not only play a supporting role, but also participate in the overall structure of the body, enhancing the vehicle's impact resistance .
Material and fixation
The materials of the beam and vertical plate of the water tank usually include metal (such as steel) and resin (engineering plastic). There are two fixing methods: bolt connection and spot welding. Metal tank frames are commonly found in gantry and semi-gantry structures, while resin tank frames are commonly found in detachable designs .
Design and function
The design of the tank beams, vertical plates and columns needs to take into account the collision safety of the vehicle and the overall structural strength. They not only support and protect important components, but also act as an energy absorber in the event of a collision, reducing injuries to passengers. Therefore, damage to these parts is often considered to be one of the signs of an accident car .
The main role of the vertical plate column of the automobile water tank beam includes the following aspects :
Improved installation stability : Tank beam installation stability can be improved by integrating tank beams into existing tank fixtures. This design eliminates support ribs and connection points in the tank fixtures, simplifying construction, enabling lightweight, and increasing mounting space in the front compartment .
To ensure the torsional rigidity and load bearing : the lower protection plate cross beam of the water tank can ensure the torsional rigidity of the frame and the ability to withstand longitudinal loads. By riveting the connection, this structure can ensure that it has sufficient strength and stiffness to effectively cope with the vehicle load and wheel impact .
support key components : the water tank beam not only supports the key components of the vehicle, but also bears the important task of supporting the key components of the vehicle. This design ensures the stability of the frame and the support of key components of the vehicle, thereby enhancing the safety and comfort of driving .
Protect the tank and condenser : The tank frame acts as a support structure to hold the tank and condenser in place, ensuring that they remain in a stable position during driving and prevent displacement or damage. At the same time, it also connects the headlights and other components to ensure the stability of the entire front section .
