What is the beam vertical plate column of the car water tank
Automobile water tank beam, vertical plate and column definition and their role in the body structure :
Tank beam : Tank beam is a part of the car body structure, usually located at the bottom of the car, made of high-strength steel. Its main role is to disperse and absorb the impact force when the vehicle is impacted, and protect the safety of the occupants of the vehicle. The shape of the tank beam is usually rectangular or trapezoidal and varies depending on the type and design of the vehicle .
water tank vertical plate : The water tank vertical plate is the support structure that fixes the car water tank and condenser, usually called the water tank frame. The material of the tank frame can be metal, resin or metal + resin composite. There are two main types of tank frames: non-removable and removable. Non-removable tank frames are usually secured by spot welding, while removable tank frames may be bolted to .
Damage to the tank frame is often considered one of the signs of an accident car, as replacing the tank frame may damage the body frame .
column : In the automobile body structure, the column refers to the main part that supports the structural strength of the vehicle, including the A pillar, the B pillar, the C pillar and the D pillar. Pillar A is located on both sides of the front windshield and mainly withstands frontal impact; The B-pillar is located between the front and rear doors and mainly withstands side impact; The C-pillar is located on both sides of the rear windshield of the three-car or two-car vehicle; The D-pillar is commonly found in SUV and MPV models and is located at the rear of the body where the roof meets the compartment. The higher the strength of these columns, the better the impact resistance of the body .
The main functions of the vertical plate column of the cross beam of the automobile water tank include improving the installation stability, simplifying the structure, lightweight and increasing the front cabin installation space . To be specific:
Improved installation stability : The installation stability of the tank beam is improved by integrating the tank beam into the existing tank fixtures and replacing the traditional support ribs and connection points.
simplified structure : By omitting the support ribs and connection points in the tank fixtures, the design of the tank beam is simplified and the structure is more compact .
lightweight : The simplified structure not only enhances the strength of the beam, but also enables the vehicle to be lightweight, helping to improve fuel economy and performance .
Increased front mounting space : The lightweight and simplified structure of the design allows for increased front mounting space, further improving vehicle performance and utility .
In addition, the water tank beam vertical plate column also has the following specific functions:
to ensure the torsional rigidity of the frame and bear the longitudinal load : the lower protection beam of the water tank is connected by riveting, with enough strength and stiffness to effectively cope with the load of the car and the impact of the wheel .
Support vehicle key components : The beam supports the key components of the vehicle to ensure the stability of the frame and the support of the key components of the vehicle, thereby improving the safety and comfort of driving .
